Dynacord L1800FD-EU DSP 2x950w Power Amplifier
Bagikan :
Deskripsi Produk
Spesifikasi Produk
Deskripsi Produk
The Dynacord L Series amplifiers offer advanced features tailored for both live and mobile applications, with integrated digital signal processing and FIR Drive technology for professional speaker management. Utilizing Class A/B and Class H topologies, these amplifiers ensure outstanding acoustic performance and reliability. Designed for mobile use, their connectivity options enhance flexibility, while a front panel LC display enables easy local control and monitoring. Additionally, intuitive system control software streamlines setup, offers flexible management, and provides comprehensive system supervision.
- Professional DSP amplifier for live and mobile application
- Fully integrated professional speaker processing with FIR drive technology
- Market-leading acoustic performance and rock solid reliability
- Intuitive, simplified set-up, control and operation in SONICUE sound system software with firmware 2.0
Spesifikasi Produk
Maximum Output Power, Single Channel
2 Ω : 1600 W ; 2.6 Ω : 1300 W ; 4 Ω : 950 W ; 8 Ω : 480 W
Maximum RMS Voltage Swing THD = 1%, 1 kHz
65.1 V
Voltage Gain Ref.1 kHz
32.0 dB
THD at 450 W/4 Ω MBW = 80 kHz, 1 kHz
< 0.05%
IMD-SMPTE, 60 Hz, 7 kHz
< 0.1%
DIM30, 3.15 kHz, 15 kHz
< 0.05%
Maximum Input Level
+21 dBu
Load Impedance
2 Ω 2.6 Ω 4 Ω 8 Ω
Frequency Response, ref. 1 kHz
10 Hz to 21 kHz (±1 dB)
Input Impedance, Active Balanced
20 k Ω
Signal to Noise Ratio Amplifier, A-weighted, ref to Max. Output Power @ 8 Ω
>104 dB
Power Requirements
240 V, 230 V, 120 V or 100 V; 50 Hz to 60 Hz (factory configured)
Power Consumption 1/8 Maximum Output Power @ 4 Ω
550 W
Mains Fuse
240 V/230 V: T10AH; 120 V/100 V: T20AH
