Hikvision DS-2CD2123G2-LI(2U) 2MP Acusense Smart Hybrid Light Fixed Bullet Network Camera
Product Code
:
DS-2CD2123G2-LI(2U)
Availability
:
In Stock
Bagikan :
Hikvision DS-2CD2123G2-LI(2U) 2MP Acusense Smart Hybrid Light Fixed Bullet Network Camera
Deskripsi Produk
Spesifikasi Produk
Deskripsi Produk
DS-2CD2123G2-LI(2U) 2MP Acusense Smart Hybrid Light Fixed Dome Network Camera
- High Quality Imaging with 2MP Resolution
- Acusense : Focus on human and vehicle classification based on deep learning
- Smart Hybrid Light : Integrates IR and White Lights, 4 supplemental lighting modes
- -2U: Built-in arrayed dual-microphone for real time high quality audio security
- Clear imaging againts strong back light due to 120 dB true WDR Technology
- Water and dust resistant (IP67), and Vandal resistant (IK10)
- Efficient H.265+ compression technology
DS-2CD2123G2-LI
DS-2CD2123G2-LI2U
Spesifikasi Produk
Camera
Image Sensor
1/2.7″ Progressive Scan CMOS
Max. Resolution
1920 x 1080
Min. Illumination
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
Shutter Time
1/3 s to 1/100.000 s
Day & Night
IR Cut Filter
Angle Adjustment
Pan: 0° to 355°,tilt: 0° to 75°,rotate: 0° to 355°
Lens
Lens Type
Fixed Focal Lens
Focal Length & FOV
2.8 mm, horizontal FOV 112°, vertical FOV 61°, diagonal FOV 132°
Lens Mount
M12
Iris Type
Fixed
Aperture
F1.6
Illuminator
Supplement Light Type
IR White Light
Supplement Light Range
IR: up to 30 m
Smart Supplement Light
YES
IR Wavelength
850nm
Video
Main Stream
50 Hz: 25 fps ( 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (1920 × 1080, 1280 × 720)
Sub Stream
50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360)
Third Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) *Third stream is supported under certain settings.
Video Compression
Main stream: H.265/H.264/H.264+/H.265+, Sub-stream: H.265/H.264/MJPEG, Third stream: H.265/H.264, *Third stream is supported under certain settings.
Video Bit Rate
32 Kbps to 8 Mbps
H.264 Type
Baseline Profile, Main Profile, High Profile
H.265 Type
Main Profile
Bit Rate Control
CBR, VBR
Audio
Interface
Built-in Microphone: -2U: Arrayed dual-microphone
-S: 1 input (line in), two core terminal block max. input amplitude: 3.3 Vpp, input impedance : 4.7KΩ
Alarm
-S: 1 input, 1 output (max. 12 VDC, 30 mA)
General
Material
Base: aluminum alloy, cover: aluminum alloy
Dimension
Ø121.5 mm × 97.6 mm (Ø4.78″ × 3.84″)
Package DImension
150 mm × 150 mm × 141 mm (5.91″ × 5.91″ × 5.55″)
Weight
Approx. 600g
With Package Weight
Approx. 830g
