Honeywell HC35W43R3 3MP IP WDR IR Mini Dome Camera
Product Code
:
HC35W43R3
Availability
:
In Stock
Bagikan :
Deskripsi Produk
Spesifikasi Produk
Deskripsi Produk
HC35W43R3
WDR 3 MP IR Dome, 2.8mm, PoE
Make your premises smart and secure with Honeywell’s 35 Series cameras ideally suited for small to medium sized business operations. These cost-effective cameras are available in a wide range of form factors and resolutions and offer integrated smart analytics, exceptional picture clarity, flexible system integration, secure data transmission, and easy installation.
FEATURES
True WDR (120 dB) ensures glare-free images
True day/night provides vivid color images by day and clear black and white images at night using a removable IR cut filter
Excellent low-light performance with 2D/3D noise reduction, saving storage and bandwidth together with smart codec
Spesifikasi Produk
OPERATIONAL
Video Standard
NTSC / PAL
Scanning System
Progressive
Image Sensor
HC35W43R3: 1/2.7” CMOS
Sensor Size (H x V)
HC35W43R3: 4.608 mm x 2.592 mm
Number Of Pixels(H x V)
HC35W43R3: 2304 x 1296
Minimum Illumination
HC35W43R3: 0.005 Lux / F1.6 (Color,30 IRE), 0 Lux / F1.6 (IR ON)
S/N Ratio
50 dB
Electronic Shutter Speed
1/8 ~ 1/32,000
IR Distance
up to 40 M
IR Light Control
Smart IR (Auto/Manual)/OFF
IR Light Number
2
Day/Night
Auto (ICR) / Color / BW
Backlight Compensation
WDR, BLC, HLC
White Balance
Auto / Tungsten / Fluorescent / Daylight / Shadow / Manual
Local Storage Micro SD
(up to 256 GB)
Alarm Inputs/Outputs
HC35W43R3: Not supported
Pan Range
0°-330°
Tilt Range
0°-75°
Rotation Range
0°-337°
VIDEO
Video Compression
H.265 HEVC/H.264/MJPEG, Smart Codec
Resolution
1st: 2304 x 1296 / 1920 x 1080 / 1280 x 720
2nd: 704 x 576 (PAL) / 704 x 480 (NTSC) / 640 x 480 / 352 x 288 (PAL) / 352 x 240 (NTSC)
3rd: 640 x 480 / 352 x 288 (PAL) / 352 x 240 (NTSC) / 320 x 240
Number of Video
Streams 3 (2 for encryption)
Frame Rate*
MAX 30 fps
Bit Rate*
HC35W43R3: 100K ~ 6 Mbps
AUDIO
Audio Compression
Not supported
Audio Stream
Not supported
Audio Interface
Not supported
NETWORK
Ethernet
10 Base-T/100 Base-TX Ethernet (RJ-45)
Supported Web Browsers
Chrome/Edge
Supported OS Microsoft
Windows 10
EVENTS / ANALYTICS
Built-in Video Analytics
Motion Detection, Tampering
Event Type
Video motion detection,Recording notification
Event Linkage
Event notification using Email and MicroSD card
Email and MicroSD card
Region Of Interest 8
ELECTRICAL
Power Supply
DC12V, PoE (IEEE 802.3af) (Class 0)
Power Consumption (Max)
MAX 3.6 W
