Uniview NVR304-32B-IQ 32 Channel NVR
Product Code
:
NVR304‑32B‑IQ
Availability
:
In Stock
Bagikan :
Deskripsi Produk
Spesifikasi Produk
Deskripsi Produk
Uniview NVR304-32B-IQ Series
NVR 32 channel 4 SATA
- Support Ultra H.265/H.265/H.264 video formats
- 32 channel input
- Supports mainstream cameras of ONVIF conformance(Profile S, Profile G, Profile T ) and RTSP protocols
- Support 1 ch HDMI, 1 ch VGA. HDMI up to 4K (3840×2160) resolution
- Support HDMI and VGA simultaneous output
- Up to 12 Megapixels resolution recording
- ANR technology to enhance the storage reliability when the network is disconnected
- Support cloud upgrade
Spesifikasi Produk
Decoding
Decoding Format
Ultra 265,H.265,H.264
Decoding Capability
Smart Off：2 x 12MP@30, 2 x 4K@30, 4 x 4MP@30, 10 x 1080P@30, 20 x 720P@30, 32 x D1
Smart On：2 x 4K@30, 4 x 4MP@30, 8 x 1080P@30, 16 x 720P@30, 32 x D1
Network
Incoming Bandwidth
160Mbps
Outgoing Bandwidth
128Mbps
Protocols
TCP/IP; P2P; NTP; DHCP; PPPoE; HTTP; HTTPS; DNS; DDNS; SNMP; SMTP; RTSP; IPv6; IPv4; 802.1x
Browser(Plugin)
Windows:IE(IE10/11),Firefox (version 52.0 and above),Chrome(version 45 and above),Edge(version 79 and above)
Video/Audio Output
Liveview Display
1/4/6/8/9/16/25/32
Corridor Mode Screen
3/4/5/7/9/10/12/16/32
Recording
Recording Resolution
12MP/8MP/6MP/5MP/4MP/3MP/1080P/960P/720P/D1/2CIF/CIF
Synchronous Playback in Local
16-ch
Smart
VCA Detection by IPC
Face Detection; Vehicle Detection; SIP (Intrusion Detection, Cross Line Detection, Enter Area, Leave Area); Ultra Motion Detection (UMD); People Counting (People Flow Counting, Crowd Density Monitoring); Traffic Monitoring
Smart by NVR
face detection; Smart Intrusion Prevention (SIP); Ultra Motion Detection(UMD)
VCA Search
Motor Vehicle Search; Non‑Motor Vehicle Search; Human Body Search; General Search; People Counting Report; Heat Map
Smart by IPC
All channels (up to 8 images/s in total)Face Detection, face detection, Vehicle Detection, SIP, UMD, Traffic Monitoring
Vehicle Picture Library
Up to 5 vehicle picture libraries,with up to 25,000 vehicle pictures in total
Hard Disk
SATA
4 SATA Interfaces
Capacity
Up to 10TB for each HDD (The maximum HDD capacity varies with environment temperature)
External Interface
Network Interface
2 RJ45 10M/100M/1000M self‑adaptive Ethernet Interface
USB
Front panel: 1 x USB2.0; Rear panel: 1 x USB2.0, 1 x USB3.0
Power Supply
DC 12V/5A
Dimensions
Weight (without HDD)
≤ 3.4Kg
Dimensions
440mm × 350mm × 48mm
